ZENNIO ZIO1X010 KNX universal actuator MINIBOX 0-10 V 1-fold

ZENNIO ZIO1X010 KNX universal actuator MINIBOX 0-10 V | 1-fold

Manufacturer: ZENNIO
Article no.: 20042533
EAN: 8411080789099
Manufacturer item number: ZIO1X010
Manufacturer type: MINiBOX 0-10V X1
Weight: 0,1 kg
Available on request
115,57 €
incl. VAT + shipping
pcs
The device has one port that can be used as either a 0-10 V output, 0-10 V input, or a configurable 4-20 mA input. It allows manual operation of the 0-10 VDC outputs, supports one fan coil module and one thermostat, as well as 10 logic functions. Data saving is ensured in the event of a power failure. The integrated KNX BCU (TP1-256) offers additional flexibility. The dimensions are 67 x 90 x 36 mm (2 DIN units) for DIN rail mounting. The device complies with CE, UKCA, and RCM guidelines and has an IP20 protection rating. It is suitable for continuous operation at temperatures from 0 to +55 degrees Celsius and weighs 80 grams.
Binary inputs integrated
Yes
Brand
ZENNIO
Class
Universal actuators
Different bus system
-
KNX
Yes
KNX-TP
Yes
Manufacturer item number
ZIO1X010
Manufacturer type
MINiBOX 0-10V X1
Mounting type
Series installation
old Voltus number
1703191
Type of transmission
Cable

The following links may lead to external websites. Voltus cannot be held responsible for the accuracy or timeliness of external content.

Produktdatenblatt (en)
Manufacturer information
ZENNIO
Zennio Avance y Tecnología S.L.
C/ Río Jarama, 132. Nave P-8.11
45007 Toledo
ES

info@zennio.com
www.zennio.com/
