WINKHAUS 4983721 Window Contact | VdS class B, opening

Manufacturer: WINKHAUS

Article no.: 20007953

EAN: 4026058175763

Manufacturer item number: 4983721

Manufacturer type: VS.B.06

Weight: 0,144 kg

In stock

Delivery: 2-3 business days

pcs

- Contact strike plate VS.B.06 and VS.B.25 for combined opening and closing monitoring - VdS-approved contact strike plate with closing contact for alarm and monitoring systems VdS no. G 106511, environmental class III - Scope of delivery: 1 contact strike plate, 3 moulded parts and 2 mounting screws - Use in combination with one of the magnetic contact transmitters E1.VS.KG, MK.VS.150.KG or MK.VS.250.KG

Technical data
Switching voltage: max. 48 V DC
Switching current: max. 0.5 A
Carrying current: max. 1.0 A
Contact resistance: max. 150 mΩ
Switching capacity: max. 10 W purely resistive load
Temperature range: -20 °C to +70 °C
Protection rating: IP67 according to DIN EN 60529
Service life: min. 10,000,000 switching cycles
Dimensions (LxWxH): 104 mm x 18 mm x 8.5 mm
Connection type: 6 m moulded-on connection cable, white, 4 x 0.14 mm², diameter 3.5 mm

Brand: WINKHAUS
Class: Contacts and detectors
Manufacturer item number: 4983721
Manufacturer type: VS.B.06
VDS: without
