WEINZIERL 5543 KNX I/O module KNX-TP, Secure

WEINZIERL 5543 KNX I/O module | KNX-TP, Secure

Manufacturer: WEINZIERL
Article no.: 20085759
EAN: 4260262775436
Manufacturer item number: 5543
Manufacturer type: KNX TP Multi IO 570.1 secure
Weight: 0,2 kg
Available on request
Electrical appliance take-back
pcs
The KNX TP Multi IO 570.1 secure is a universal input and output module for building control. It offers 48 digital channels. Each channel can be used as a binary input or as a binary output. The peripherals (e.g. relays) are powered by an external power supply (24 V⎓). Input channels can be used to control, for example, lights or blinds via KNX. They can also be configured as pulse counters – for example, for energy meters. Output channels can directly control signal LEDs, external coupling relays (e.g. Multi IO Extension Switch 590), or blind relays (Multi IO Extension Shutter 592).

The integrated USB interface enables a connection between a PC and the KNX bus. The USB port is galvanically isolated from the KNX bus. Configuration is carried out via ETS (version 5.7 or higher), and local programming is possible.
BAB-Tec
No
Bluetooth
No
Brand
WEINZIERL
Casambi
No
Class
Binary input
Colour
white
Configuration
binary
DALI
No
Division units
6 TE
ENOcean
No
free@home
No
Gira One
No
Hager KNXeasy
No
Installation location
distribution cabinet
JUNG HOME
No
KNX
Yes
KNX-RF
No
KNX-Secure
Yes
KNX-TP
Yes
Manufacturer item number
5543
Manufacturer type
KNX TP Multi IO 570.1 secure
Matter
No
Mbus
No
Modbus
No
Modbus RTU
No
Modbus TCP
No
Mounting type
Series installation
Number of inputs
48
Potential free
No
Shelly
No
Siemens LOGO!
No
Theben LUXORliving
No
Thread
No
Type of transmission
Cable
Wi-Fi
No
Wiser Home
No
with Netatmo
No
Zigbee
No

The following links may lead to external websites. Voltus cannot be held responsible for the accuracy or timeliness of external content.

Data Sheet
Manufacturer information
WEINZIERL
Weinzierl Engineering GmbH
Achatz 3-4
84508 Burgkirchen an der Alz
DE

info@weinzierl.de
weinzierl.de/
