THEBEN theMova S360-100 AP WH theMova passive infrared motion detector 360°, ceiling mounting, surface-mounted | white

THEBEN theMova S360-100 AP WH theMova passive infrared motion detector | 360°, ceiling mounting, surface-mounted | white

Manufacturer: THEBEN
Article no.: 20056464
EAN: 7612748005013
Manufacturer item number: 1030550
Manufacturer type: theMova S360-100 AP WH
Weight: 0,286 kg
Available on request
Electrical appliance take-back
pcs
The passive infrared motion detector is designed for ceiling mounting and features a well-thought-out design that allows for easy installation and flexible adaptation to different room situations.

  • 360° detection range with an 8 m diameter: Covers an area of 50 m² at a mounting height of 3 m and enables reliable motion detection indoors.
  • Automatic light control with daylight sensor: Controls lighting based on motion and brightness, with adjustable brightness switching values.
  • Flexible adjustment options: Follow-up time and sensitivity are adjustable; factory presets enable immediate commissioning.
  • Remote parameter setting via theSenda remote controls: Settings can be conveniently adjusted remotely after installation without a ladder.
  • Surface-mounted ceiling installation with IP54 protection class: Easy installation without a mounting opening, protection against dust and splashing water for harsh environments.
  • Compatible with various lamp types: Suitable for incandescent, halogen, fluorescent, and LED lamps.
  • Ambient temperature range from -15°C to 50°C: Suitable for various indoor temperatures.
  • Additional functions impulse mode and test mode: Supports staircase lighting operation and facilitates on-site function testing.


This white motion detector for surface-mounted ceiling installation allows for easy and quick installation without a mounting opening. It automatically controls lighting depending on ambient brightness and detected motion. Its round detection area covers a diameter of up to 8 metres. For optimal adaptation to the respective room situation, the switch-off delay and sensitivity are adjustable. The device is supplied with preset values, ensuring immediate readiness for operation after installation. Convenient remote parameter setting is also possible, so settings can be changed afterwards without a ladder.

The passive infrared motion detector for ceiling mounting offers a 360° round detection area with an 8 m diameter and covers 50 m² at a mounting height of 3 m. It automatically controls lighting depending on motion and brightness. With a daylight sensor mode that can be switched via app, the detector is especially suitable for indoor use as a fully automatic device. The brightness switching values are adjustable, as are the follow-up time and sensitivity. Functions such as impulse mode for staircase lighting and a test function are also available. The device is factory preset; changes are made via the optional theSenda B, theSenda P, or theSenda S remote controls. Installation is on the ceiling, and the detector is designed for an ambient temperature range of -15°C to 50°C. It has a protection rating of IP54 and is suitable for various lamp types such as incandescent, halogen, fluorescent, and LED lamps.
Acoustic sensor
No
Area
Inside
Brand
THEBEN
Brightness sensor
No
Class
Motion detector
CO2 sensor
No
Colour
white
Crawl protection
No
DALI-2
No
Detection area
circular
Detection type/sensor type
Passive infrared
Integrated constant light control
No
LED night light
No
Manufacturer item number
1030550
Manufacturer type
theMova S360-100 AP WH
Manufacturer's colour
white
Material
Plastic
Mounting type
Surface-mounted
Protection class (IP)
IP54
Remote controllable
Yes
suitable for ceiling mounting
Yes
suitable for installation in switch ranges
No
suitable for wall mounting
No
Surface
matt
Temperature sensor
No
