THEBEN RM 8 T KNX Universal Actuator | 8-fold

Manufacturer: THEBEN

Article no.: 20040407

EAN: 4003468490839

Manufacturer item number: 4940200

Manufacturer type: RM 8 T KNX

Weight: 0,367 kg

In stock

Delivery: 4-8 business days

pcs

This compact KNX combination actuator is a flexible solution for DIN rail mounting. At only 4 TE wide, it offers relay outputs that can be configured either as 8 switching channels or 4 shutter channels. Communication is protected by KNX TP Data Secure. Each channel features an LED indicator and a manual switch with status display. The actuator supports numerous functions such as staircase lighting with pre-warning according to DIN 18015-2, logical links (locking, AND, OR), scenes, and central commands. A feedback object for each channel ensures transparency in building management.

Switch/Shutter actuator 8/4-fold, without extension RM 8 T KNX bus system KNX, other bus systems none, mounting type REG, width in modular units 4, local/manual operation, with LED indicator, number of digital inputs 0, max. switching power 2000 W, max. LED switching power 600 W, output power 3680 W, max. number of switching outputs 8, max. switching current 16 A, rated current 16 A, rated operating voltage 110 ... 230 V, various phases connectable, with bus coupling, protection class (IP) IP20,

BAB-Tec: No
Binary inputs integrated: No
Blinds: Yes
Bluetooth: No
Brand: THEBEN
Casambi: No
Class: Universal actuators
DALI: No
Different phases can be connected: Yes
Dimming: No
Division units: 8 TE
ENOcean: No
Fan coil: No
free@home: No
Gira One: No
Hager KNXeasy: No
JUNG HOME: No
KNX: Yes
KNX-RF: No
KNX-Secure: No
KNX-TP: Yes
Local/manual operation: Yes
Manufacturer item number: 4940200
Manufacturer type: RM 8 T KNX
Matter: No
Mbus: No
Modbus: No
Modbus RTU: No
Modbus TCP: No
Mounting type: Series installation
Number of blind outputs: 8
Number of outputs: 16
Rated voltage outputs: 230V AC
Shelly: No
Siemens LOGO!: No
Size of connection terminal in mm2: 2.5
suitable for C load: No
Switch: Yes
Theben LUXORliving: Yes
Thread: No
Type of transmission: Cable
Wi-Fi: No
Wiser Home: No
with Netatmo: No
Zigbee: No

The following links may lead to external websites. Voltus cannot be held responsible for the accuracy or timeliness of external content.

Data Sheet

Manual

Declaration of Conformity

Manufacturer information

THEBEN
Theben AG
Hohenbergstr. 32
72401 Haigerloch
DE

info@theben.de
www.theben.de/
