THEBEN CHEOPS S KNX Actuator standard

THEBEN CHEOPS S KNX Actuator | standard

Manufacturer: THEBEN
Article no.: 20033123
EAN: 4003468730027
Manufacturer item number: 7319205
Manufacturer type: CHEOPS S KNX
Weight: 0,229 kg
Available on request
Electrical appliance take-back
pcs


This motorised KNX actuator is a highly intelligent solution for the precise control of heating and cooling valves in modern building automation. It features secure commissioning and communication thanks to support for KNX Data Secure. An integrated temperature sensor as well as a built-in controller for efficient heating and cooling, each with an additional stage, make it an autonomous control unit. With a high actuating force of up to 220 N and a maximum valve stroke of 8 mm, it operates powerfully and precisely. Two universal binary inputs allow the connection of external components such as temperature sensors or window contacts. Automatic valve adaptation and the supplied adapters for the most common valves (M30x1.5 and Danfoss) ensure universal use, including in the heating circuit distributor. The bus coupler is already integrated.

Actuator Cheops S KNX Bus system KNX, Mounting type radiator valve, With bus coupling, Temperature controller with continuous control built-in, Temperature and stroke display, Master/Slave function, Number of digital inputs 0, Bus power supply, Protection rating (IP) IP21.
Apple HomeKit
No
BAB-Tec
No
Blinds
No
Bluetooth
No
Brand
THEBEN
Casambi
No
Class
Actuators
DALI
No
Dimming
No
ENOcean
No
Fan coil
No
free@home
No
Gira One
No
Google Assistant
No
Hager KNXeasy
No
Home Assistant
No
JUNG HOME
No
KNX
Yes
KNX-RF
No
KNX-Secure
Yes
KNX-TP
Yes
Local/manual operation
No
Manufacturer item number
7319205
Manufacturer type
CHEOPS S KNX
Matter
No
Mbus
No
Modbus
No
Modbus RTU
No
Modbus TCP
No
Mounting type
radiator valve
Number of outputs
1
Samsung SmartThings
No
Shelly
No
Siemens LOGO!
No
Switch
No
Theben LUXORliving
No
Thread
No
Type of transmission
Cable
Wi-Fi
No
Wiser Home
No
with Netatmo
No
Zigbee
No

The following links may lead to external websites. Voltus cannot be held responsible for the accuracy or timeliness of external content.

Declaration of Conformity
Data sheet
Manufacturer information
THEBEN
Theben AG
Hohenbergstr. 32
72401 Haigerloch
DE

info@theben.de
www.theben.de/
