SMARTFOX 0791732486650 Current Transformer | 500 A, divisible

Manufacturer: SMARTFOX

Article no.: 20026433

EAN: 0791732486650

Manufacturer item number: 0791732486650

Manufacturer type: 0791732486650

Weight: 0,001 kg

Available on request

pcs

Additional split-core current transformer for SMARTFOX Pro and SMARTFOX Pro Light for measuring currents up to 500A; 1 pc.

Technical data:
Primary/secondary current: 500/5A
Minimum primary power: 5VA
Rated secondary voltage: 0.33 VAC
Isolation/primary voltage max.: 600 VAC / 5000 VAC
Operating temperature: -15 degrees Celsius to +60 degrees Celsius
Frequency range: 50-400Hz
Secondary connection cables: 105cm / 2.5mm² (plug-on, no cable)
Measurement tolerance: Class 1
Certification: RoHS / CE

For further information / technical data please refer to the manufacturer’s datasheet (under documentation).

Brand: SMARTFOX
Class: Current transformer
Current in A: 500
Manufacturer item number: 0791732486650
Manufacturer type: 0791732486650
