SIEMENS 5SV1316-7LK10 RCD/MCB Type A C-Char. 30 mA 1+N 10 A, short-time delayed

SIEMENS 5SV1316-7LK10 RCD/MCB Type A C-Char. 30 mA 1+N | 10 A, short-time delayed

Manufacturer: SIEMENS
Article no.: 20011449
EAN: 4001869558097
Manufacturer item number: 5SV1316-7LK10
Manufacturer type: 5SV1316-7LK10
Weight: 0,132 kg
Available on request
Electrical appliance take-back
pcs
FI/LS circuit breaker compact type A(G), 30mA, C10 5SV1316-7LK10 Number of poles (total) 2, Number of protected poles 1, Rated voltage 230V, Rated insulation voltage Ui 253V, Rated impulse withstand voltage Uimp 4kV, Rated current 10A, Rated residual current 0.03A, Residual current type A, Energy limitation class 3, Rated breaking capacity according to EN 61009 6kA, Rated breaking capacity according to IEC 60947-2 10kA, Rated making capacity Icn according to EN 61009-1 6kA, Tripping characteristic short-time delayed, Surge current withstand 3kA, Voltage type AC, Frequency 50 Hz, Tripping characteristic C, Switched neutral conductor, With locking device, Overvoltage category 2, Pollution degree 2, Ambient temperature during operation -25 ... 45°C, Width in modular units 1, Installation depth 70mm, Flush-mounted installation, False trip protection, Protection class (IP) IP20, Connectable conductor cross-section solid 0.75 ... 16mm², Connectable conductor cross-section stranded 0.75 ... 16mm²,
Brand
SIEMENS
Breaking capacity in kA
3
Class
FI/LS switch
Configuration
2-pole
Division units
1 TE
Fault current in mA
30
Fault current type
Type A
Manufacturer item number
5SV1316-7LK10
Manufacturer type
5SV1316-7LK10
Positioning neutral wire
right
Rated current in A
10
