SIEMENS 5SU1356-6KK10 RCD/MCB switch type A B-char. 30 mA 1+N 10 A, instantaneous

SIEMENS 5SU1356-6KK10 RCD/MCB switch type A B-char. 30 mA 1+N | 10 A, instantaneous

Manufacturer: SIEMENS
Article no.: 20046475
EAN: 4001869306704
Manufacturer item number: 5SU1356-6KK10
Manufacturer type: 5SU1356-6KK10
Weight: 0,27 kg
In stock
Delivery: 2-3 business days
Electrical appliance take-back
pcs
FI/LS switch type A, 30mA, B10 5SU1356-6KK10


Number of poles (total) 2, number of protected poles 1, rated voltage 230V, rated insulation voltage Ui 264V, rated impulse withstand voltage Uimp 4kV, rated current 10A, rated residual current 0.03A, residual current type A, energy limitation class 3, rated breaking capacity according to EN 61009 6kA, rated breaking capacity according to IEC 60947-2 15kA, rated short-circuit breaking capacity Icn according to EN 61009-1 6kA, tripping characteristic instantaneous, surge current withstand 1kA, voltage type AC, frequency 50 Hz, tripping characteristic B, with switched neutral conductor, with locking device, overvoltage category 2, pollution degree 2, ambient temperature during operation -25 ... 55°C, width in modular units 2, installation depth 70mm, flush mounting, false trip protection, protection rating (IP) IP20, connectable conductor cross-section solid 0.75 ... 35mm², connectable conductor cross-section stranded 0.75 ... 35mm²,
Brand
SIEMENS
Class
FI/LS switch
Division units
2 TE
Fault current type
Type A
Manufacturer item number
5SU1356-6KK10
Manufacturer type
5SU1356-6KK10
Manufacturer information
SIEMENS
Siemens AG Digital Industries Deutschland
Siemenspromenade 2
91058 Erlangen
DE

contact@siemens.com
www.siemens.com/

Hints
  • Bei einem nicht steckerfertigen elektrischen Gerät oder Bauteil dürfen Anschluss und Installation nur von einer qualifizierten Elektrofachkraft durchgeführt werden. Bitte beachte auch die Gebrauchsanweisung.
