SCHNEIDER R9L2C640 Surge Arrester Resi9 Type 2+3 3-pole, 40 kA

SCHNEIDER R9L2C640 Surge Arrester Resi9 Type 2+3 | 3-pole, 40 kA

Manufacturer: SCHNEIDER
Article no.: 20070159
EAN: 3606486808467
Manufacturer item number: R9L2C640
Manufacturer type: R9L2C640
Weight: 0,296 kg
Available on request
Electrical appliance take-back
pcs
Acti9 iPRD C40r modular surge arrester Type 2+3 in a compact design – only 2TE wide. Max. supply-side overcurrent protection 100A gG. Remote signalling contact. Optical function/fault indicator of the arrester (green OK/ red device fault). Suitable for TN-S and TT networks. U0 rated voltage 230 V AC (50/60Hz). Uc – maximum continuous voltage 255VAC (N-PE) / 275VAC (L-N). In rated discharge current 20 kA (L-N)/(N-PE). Imax – maximum discharge current 40 kA (L-N)/(N-PE). Uoc no-load voltage 6kV (L-N/N-PE). Up protection level 1.5 kV (Type 2+3) for (L-N/N-PE). Up protection level 1.0 kV (Type 3) for (L-N/N-PE). DIN rail mounting. Dimensions (W) 36mm x (H) 99mm x (D) 70mm. Weight 262g. Protection rating IP20 integrated. Operating temperature -40 to +85 degrees Celsius. Complies with IEC 61643-11:2011, EN 61643-11:2012+A11:2018.
Brand
SCHNEIDER
Class
Overvoltage protection
Configuration
3-pole
Manufacturer item number
R9L2C640
Manufacturer type
R9L2C640
Mounting type
Series installation
Type
2 | 3
Manufacturer information
SCHNEIDER
Schneider Electric GmbH
Gothaer Str. 29
40880 Ratingen
DE

de-gh@se.com
www.se.com/

Hints
  • Bei einem nicht steckerfertigen elektrischen Gerät oder Bauteil dürfen Anschluss und Installation nur von einer qualifizierten Elektrofachkraft durchgeführt werden. Bitte beachte auch die Gebrauchsanweisung.
Recycling & disposal
Informationen zum Bereich Recycling & Entsorgung findest du hier: https://www.voltus.de/umweltschutz/.
