MÖHLENHOFF 137226 Base Station Balance Switch 230 V, 8-channel, NFC

MÖHLENHOFF 137226 Base Station Balance Switch | 230 V, 8-channel, NFC

Manufacturer: MÖHLENHOFF
Article no.: 20060128
EAN: 4031602013637
Manufacturer item number: 137226
Manufacturer type: B 21903-08N
Weight: 0,71 kg
Available on request
Electrical appliance take-back
pcs
Electronic wired base station B 21903-08N2 230 V for controlling water-based surface heating/cooling systems. Up to 8 heating zones independently controllable with up to 12 thermal actuators in 230 V version, normally closed (NC). Compatible with standard heating controllers. With pump logic (switching capacity 2A) and heat generator logic (switching capacity 2A), wired connection. TÜV certified according to the "automatic hydraulic balancing", compliant with GEG

Outputs:
Relay (pump): 2 A, 200 VA inductive
Relay (heat generator): 2 A, 200 VA inductive

Inputs:
Setback input
Change-over (potential-free)
Dew point monitor
Overtemperature limiter

Technical data:
Permissible ambient temperature: 0 to 50°C
Operating voltage: 230 V / ±10% / 50 Hz
Max. power consumption: 50 W (without pump)
Max. number of heating zones: 8
Max. number of actuators (230 V): 12 (freely assignable)
Protection rating/class: IP 20
Brand
MÖHLENHOFF
Manufacturer item number
137226
Manufacturer type
B 21903-08N
Manufacturer information
MÖHLENHOFF
Möhlenhoff GmbH
Museumstr. 54a
38229 Salzgitter
DE

kontakt@moehlenhoff.de
www.moehlenhoff.de/

Hints
  • Bei einem nicht steckerfertigen elektrischen Gerät oder Bauteil dürfen Anschluss und Installation nur von einer qualifizierten Elektrofachkraft durchgeführt werden. Bitte beachte auch die Gebrauchsanweisung.
