JUNG SSD 5-00 Antenna Socket | 3-way, universal, stitch, 1 dB

Manufacturer: JUNG

Article no.: 20038450

EAN: 4011377332256

Manufacturer item number: SSD 5-00

Manufacturer type: SSD 5-00

Weight: 0,112 kg

In stock

Delivery: 2-3 business days

pcs

3-hole universal SAT/BK socket 1.0 dB, single socket SSD 5-00 version outlet socket, installation type flush-mounted, cover without, connection attenuation at 860 MHz 1.5 dB, connection attenuation at 2150 MHz 15 dB, number of outlets 3, fastening type claw/screw fastening, halogen-free, device width 68 mm, device height 68 mm, device depth 39 mm, min. depth of device box 32 mm,

Brand: JUNG
Class: Antenna sockets
Configuration: Stitch box
Manufacturer item number: SSD 5-00
Manufacturer type: SSD 5-00
Mounting type: can
Series: A 550 | A creation | A Cube | A flow | A Viva | AS 500 | CD 500 | CD Aufputz | CD plus | LS 1912 | LS 990 | LS Cube | LS design | LS Plus | LS Zero

The following links may lead to external websites. Voltus cannot be held responsible for the accuracy or timeliness of external content.

Data Sheet

Manufacturer information

JUNG
Albrecht Jung GmbH & Co. KG
Volmestr. 1
58579 Schalksmühle
DE

kundencenter@jung.de
www.jung-group.com/de-DE/

Hints

Bei einem nicht steckerfertigen elektrischen Gerät oder Bauteil dürfen Anschluss und Installation nur von einer qualifizierten Elektrofachkraft durchgeführt werden. Bitte beachte auch die Gebrauchsanweisung.

Recycling & disposal

Informationen zum Bereich Recycling & Entsorgung findest du hier: https://www.voltus.de/umweltschutz/.

Description

Specifications

Brand: JUNG
Class: Antenna sockets
Configuration: Stitch box
Manufacturer item number: SSD 5-00
Manufacturer type: SSD 5-00
Mounting type: can
Series: A 550 | A creation | A Cube | A flow | A Viva | AS 500 | CD 500 | CD Aufputz | CD plus | LS 1912 | LS 990 | LS Cube | LS design | LS Plus | LS Zero
