JUNG CO2AL2178 KNX CO2 Sensor Series LS standard | aluminum

JUNG CO2AL2178 KNX CO2 Sensor Series LS | standard | aluminum

Manufacturer: JUNG
Article no.: 20016108
EAN: 4011377084117
Manufacturer item number: CO2AL2178
Manufacturer type: CO2AL2178
Weight: 0,112 kg
In stock
Delivery: 2-3 business days
Electrical appliance take-back
pcs
KNX CO2 Sensor, Aluminium with Integrated Bus Coupler, Humidity Sensor and Room Temperature Controller with Integrated 2-Gang Push Button Interface



Intended Use

Measuring CO2 concentration, relative humidity and air temperature

Output of measured values as telegrams on the bus, e.g. for controlling fans or window drives via KNX telegrams

Individual room temperature control in KNX installations

Mounting in device box with dimensions according to DIN 49073



Product Features

Limit value monitoring for CO2 concentration (max. 4 limit values) and humidity (max. 2 limit values)

Dew point alarm, e.g. for chilled ceilings and conservatories, to prevent mould formation

Two binary inputs for connection of potential-free contacts, e.g. push buttons, switches, window contacts

Logic gate for simple linkage functions

KNX medium: TP 256

Nominal voltage KNX: DC 21 ... 32 V SELV

Current consumption KNX: typ. 12.5 mA max.
Air pressure sensor
No
BAB-Tec
No
Bluetooth
No
Brand
JUNG
Brightness sensor
No
Casambi
No
Class
sensor
CO2 sensor
Yes
Colour
silver
DALI
No
ENOcean
No
fits in 55 switch range
No
free@home
No
Gira One
No
Hager KNXeasy
No
Humidity sensor
No
Installation location
Wall
Integrated controller
Yes
JUNG HOME
No
KNX
Yes
KNX-RF
No
KNX-Secure
No
KNX-TP
Yes
Manufacturer item number
CO2AL2178
Manufacturer type
CO2AL2178
Material
Plastic
Matter
No
Mbus
No
Modbus
No
Modbus RTU
No
Modbus TCP
No
Mounting type
flush-mounted
Rain
No
Shelly
No
Siemens LOGO!
No
suitable for installation in switch ranges
Yes
Surface
matt
Temperature sensor
No
Theben LUXORliving
No
Thread
No
Type of transmission
Cable
VOC sensor
No
Wi-Fi
No
Wind
No
Wiser Home
No
with display
No
with Netatmo
No
Zigbee
No
