JUNG AL3281-1D KNX motion detector series LS | 2.20 m, universal | dark

Manufacturer: JUNG

Article no.: 20018194

EAN: 4011377156265

Manufacturer item number: AL3281-1D

Manufacturer type: AL 3281-1 D

Weight: 0,037 kg

Available on request

172,75 €

incl. VAT + shipping

pcs

Universal for bus coupling unit 3, item no.: 2073 U. With the sealing set, item no.: AS CD 50 DS, and the program-specific "IP 44 frame," protection level IP 44 is guaranteed. IP 44 installation permitted indoors and outdoors. ETS product family: Physical sensors. Product type: Motion detector. Intended use: Demand-based control of lighting and other electrical loads. Mounting on bus coupling unit 3.

Brand: JUNG
Class: Motion detector
Color: black
Crawl protection: Yes
Detection angle in °: 80
Detection area: circular
Detection area diameter in m: 10
Detection type/sensor type: Passive infrared
Different bus system: -
Frontal range in m: 8.00
Horizontal detection angle: 180
Installation height in m: 1.10
Installation location: Wall
KNX: Yes
KNX-TP: Yes
Manufacturer item number: AL3281-1D
Manufacturer type: AL 3281-1 D
Manufacturer's color: dark
Mounting type: flush-mounted
Number of areas: 1
old Voltus number: 1662176
Reach laterally in m: 6.00
suitable for installation in switch ranges: Yes
suitable for wall mounting: Yes
Supply voltage: BUS voltage
Surface: matt
Type of transmission: Cable
