HAGER FP93SN2 Wall Cabinet IP44 SKII 3 fields | 1400 mm

HAGER FP93SN2 Wall Cabinet IP44 SKII | 3 fields | 1400 mm

Manufacturer: HAGER
Article no.: 20008729
EAN: 3250612668571
Manufacturer item number: FP93SN2
Manufacturer type: FP93SN2
Weight: 29,75 kg
Available on request
Electrical appliance take-back
pcs
Cabinet, universal, IP44/II, 1400x800x205mm, empty. Surface-mounted cabinet for indoor installation with VDE certificate (production monitoring) according to DIN EN 61439-1/-3 and dimensional standard DIN 43870, suitable for surface-mounted, flush-mounted or semi-recessed installation. For assembling a low-voltage distribution up to 400 A, 3AC 230/400 V 50 Hz. Protection rating IP44, protection class II, air and creepage distances according to DIN VDE 0110-1/-2. Consisting of cabinet with door made of powder-coated, baked, strongly profiled 1 mm thick steel sheet, interior lining made of plastic. Through flanges installed at the top and bottom of each section, rear embossing in the plastic part and busbar feed-throughs as double-sided lateral embossing in the lower area. Door flush with the front, with internal adjustable hinges, optionally hinged on the right or left with a 110-degree opening angle. Door with latch, from a width of 800 mm and for all cabinets from a height of 1250 mm with rod lock with three-point locking.
Brand
HAGER
Class
Modular cabinets
Colour
white
Depth in mm
205
Height in mm
1400
Impact resistance
IK09
Manufacturer item number
FP93SN2
Manufacturer type
FP93SN2
Mounting type
Ground setup
Number of distribution panels
3
Protection class (IP)
IP44
Width in mm
800

The following links may lead to external websites. Voltus cannot be held responsible for the accuracy or timeliness of external content.

Deeplink
Manufacturer information
HAGER
Hager Vertriebsges.mbH&Co.KG
Zum Gunterstal
66440 Blieskastel
DE

info@hager.de
hager.com/de

Hints
  • Bei einem nicht steckerfertigen elektrischen Gerät oder Bauteil dürfen Anschluss und Installation nur von einer qualifizierten Elektrofachkraft durchgeführt werden. Bitte beachte auch die Gebrauchsanweisung.
Recycling & disposal
Informationen zum Bereich Recycling & Entsorgung findest du hier: https://www.voltus.de/umweltschutz/.
