HAGER ADZ310D FI/LS switch type A B-Char. 30mA 3P+N 10A

HAGER ADZ310D FI/LS switch type A B-Char. 30mA 3P+N | 10A

Manufacturer: HAGER
Article no.: 20008308
EAN: 3250611020134
Manufacturer item number: ADZ310D
Manufacturer type: ADZ310D
Weight: 0,409 kg
In stock
Delivery: 4-8 business days
156,82 €
incl. VAT + shipping
pcs
Residual current circuit breaker 3x 1P+N 6kA B-10A 30mA Type A QuickConnect. Residual current circuit breaker according to DIN EN 61009-1 (VDE 0664-20) with 3 x 1-pole circuit breakers for 230 V AC circuits and a residual current device in a compact housing. QuickConnect terminal according to DIN EN 60898-1 (VDE 0641-11), up to 16 A on the outgoing circuit and up to 63 A on the incoming circuit, with a blue test button and residual current indicator. Easy individual removal from the busbar system. Suitable for retrofitting additional devices. Labeling option directly on the device.
Brand
HAGER
Breaking capacity in kA
3.00
Class
FI/LS switch
Configuration
4-pole
Division units
4
Fault current in mA
30
Fault current type
Type A
Manufacturer item number
ADZ310D
Manufacturer type
ADZ310D
old Voltus number
1663219
Positioning neutral wire
right
Rated current in A
10.00

The following links may lead to external websites. Voltus cannot be held responsible for the accuracy or timeliness of external content.

Deeplink
Manufacturer information
HAGER
Hager Vertriebsges.mbH&Co.KG
Zum Gunterstal
66440 Blieskastel
DE

info@berker.de
hager.com/de

Hints
  • Bei einem nicht steckerfertigen elektrischen Gerät oder Bauteil dürfen Anschluss und Installation nur von einer qualifizierten Elektrofachkraft durchgeführt werden. Bitte beachte auch die Gebrauchsanweisung.
Recycling & disposal
Informationen zum Bereich Recycling & Entsorgung findest du hier: https://www.voltus.de/umweltschutz/.
