GIRA 217100 KNX dimmer actuator old REG | 1-fold

Manufacturer: GIRA

Article no.: 20024059

EAN: 4010337082200

Manufacturer item number: 217100

Manufacturer type: 217100

Weight: 0,257 kg

In stock

Delivery: 4-8 business days

pcs

Dimming actuator 1-fold for KNX 20 - 500 W VA REG plus Features:

Dimming actuator with integrated bus coupling.
Switching and dimming of incandescent lamps, HV halogen lamps, dimmable HV LED lamps, dimmable compact fluorescent lamps, dimmable inductive transformers with LV halogen or LV LED lamps, dimmable electronic transformers with LV halogen or LV LED lamps.
Automatic or manual selection of the dimming principle suitable for the load.
No-load, short-circuit and overtemperature protection.
Manual operation of the outputs independently of the bus (also possible for construction site operation).
The 1-fold dimming actuator can also be used as a speed controller for speed control of single-phase electric motors.
Construction site operation: Outputs manually operable without bus voltage, only with the operating voltage.

Functions:
Independent control of the dimming channels.
In construction site operation, the outputs are manually operable without bus voltage, only with the operating voltage.
Central switching function for controlling all dimming channels.

Active power measurement: No
BAB-Tec: No
Blinds: No
Bluetooth: No
Brand: GIRA
Casambi: No
Class: Dimming actuators
DALI: No
Day/night function: No
Different phases can be connected: No
Dimming: Yes
Dimming method: Phase lead/edge
Division units: 4 TE
ENOcean: No
Fan coil: No
free@home: No
Gira One: No
Hager KNXeasy: No
JUNG HOME: No
KNX: Yes
KNX-RF: No
KNX-Secure: No
KNX-TP: Yes
Local/manual operation: Yes
Manufacturer item number: 217100
Manufacturer type: 217100
Matter: No
Mbus: No
Modbus: No
Modbus RTU: No
Modbus TCP: No
Mounting type: Series installation
Number of outputs: 1
Output power in W: 500
Parallel operation of channels possible: No
Rated voltage outputs: 230V AC
Shelly: No
Siemens LOGO!: No
Size of connection terminal in mm2: 4
Switch: Yes
Theben LUXORliving: No
Thread: No
Type of transmission: Cable
Wi-Fi: No
Wiser Home: No
with Netatmo: No
Zigbee: No

The following links may lead to external websites. Voltus cannot be held responsible for the accuracy or timeliness of external content.

Deeplink

Data Sheet

Manufacturer information

GIRA
GIRA Giersiepen GmbH & Co. KG
Dahlienstr. 12
42477 Radevormwald
DE

info@gira.de
www.gira.de/

Hints

Bei einem nicht steckerfertigen elektrischen Gerät oder Bauteil dürfen Anschluss und Installation nur von einer qualifizierten Elektrofachkraft durchgeführt werden. Bitte beachte auch die Gebrauchsanweisung.

Recycling & disposal

Informationen zum Bereich Recycling & Entsorgung findest du hier: https://www.voltus.de/umweltschutz/.
