ELTAKO 30200331 Radio actuator impulse relay switch 2 normally closed contacts, 10 A

ELTAKO 30200331 Radio actuator impulse relay switch | 2 normally closed contacts, 10 A

Manufacturer: ELTAKO
Article no.: 20066316
EAN: 4010312313190
Manufacturer item number: 30200331
Manufacturer type: FSR61LN-230V
Weight: 0,058 kg
Available on request
Electrical appliance take-back
pcs
2 changeover contacts for two-pole switching of L and N 10A/250V AC, 230V LED lamps up to 400W, incandescent lamps 2000 watts, drop-out delay with switch-off pre-warning and push-button permanent light can be switched on. Encrypted radio, bidirectional radio and repeater function can be switched on. Standby loss only 0.8 watts. For flush mounting. 45mm long, 45mm wide, 33mm deep. Supply, switching and control voltage locally 230V. In the event of a power failure, the switching state is retained. When the supply voltage returns, it is switched off in a defined manner. After installation, wait for the automatic short synchronisation before connecting the switched consumer to the mains. In addition to the radio control input via an internal antenna, this radio actuator can also be locally controlled with a conventional control push-button possibly mounted beforehand. A glow lamp current is not permitted.
Brand
ELTAKO
Class
relay
Configuration
Power relay
Manufacturer item number
30200331
Manufacturer type
FSR61LN-230V
Manufacturer information
ELTAKO
Eltako GmbH
Hofener Str. 54
70736 Fellbach
DE

info@eltako.de
www.eltako.com/de/

Hints
  • Bei einem nicht steckerfertigen elektrischen Gerät oder Bauteil dürfen Anschluss und Installation nur von einer qualifizierten Elektrofachkraft durchgeführt werden. Bitte beachte auch die Gebrauchsanweisung.
