ELTAKO 30100868 Radio DALI Gateway bidirectional for flush-mounted boxes

ELTAKO 30100868 Radio DALI Gateway | bidirectional for flush-mounted boxes

Manufacturer: ELTAKO
Article no.: 20066318
EAN: 4010312320921
Manufacturer item number: 30100868
Manufacturer type: FDG62-230V
Weight: 0,207 kg
Available on request
Electrical appliance take-back
pcs
Radio DALI Gateway, bidirectional for flush-mounted box.

Standby loss only 0.5 watts. For flush mounting. 49x51 mm, 20 mm deep. The connection terminals are plug-in terminals for conductor cross-sections from 0.2 mm² to 2.5 mm². With the convenient tap technology, up to 32 radio universal push-buttons, radio directional push-buttons, radio central control push-buttons, motion sensors, white tone and intensity double rocker push-buttons can be programmed.

Bidirectional radio can be activated. Supply voltage 230 V at terminals N and L. The DALI bus power supply DL-N2-80mA and up to 40 DALI devices are connected to the DALI terminals. The gateway controls DALI devices with EnOcean radio transmitters. Only the broadcast command can be sent.

In addition to the radio control input via an internal antenna, the connected DALI devices can also be controlled with a 230 V control push-button, which may be mounted in front of it.
Amazon Alexa
No
Apple HomeKit
No
BAB-Tec
No
Bluetooth
No
Brand
ELTAKO
Casambi
No
Class
DALI gateway
DALI
Yes
ENOcean
No
free@home
No
Gira One
No
Google Assistant
No
Hager KNXeasy
No
JUNG HOME
No
KNX
No
KNX-RF
No
KNX-Secure
No
KNX-TP
No
Manufacturer item number
30100868
Manufacturer type
FDG62-230V
Mounting type
flush-mounted
Samsung SmartThings
No
Shelly
No
Siemens LOGO!
No
Theben LUXORliving
No
Type of transmission
radio
Wiser Home
No
with Netatmo
No
Zigbee
No
Manufacturer information
ELTAKO
Eltako GmbH
Hofener Str. 54
70736 Fellbach
DE

info@eltako.de
www.eltako.com/de/
