ABB S203-C10 circuit breaker 3-pole type C 10A

ABB S203-C10 circuit breaker 3-pole type C | 10A

Manufacturer: ABB
Article no.: 20000169
EAN: 4016779467803
Manufacturer item number: 2CDS253001R0104
Manufacturer type: S203-C10
Weight: 0,375 kg
Available on request
22,80 €
incl. VAT + shipping
pcs
Circuit breaker 6kA 10A C 3p S203-C10 Installation depth 69mm, Tripping characteristic C, Number of poles (total) 3, Number of protected poles 3, Rated current 10A, Rated voltage 400V, Rated insulation voltage Ui 440V, Rated impulse withstand voltage Uimp 4kV, Rated breaking capacity Icn according to EN 60898 at 230V 6kA, Voltage type AC/DC, Rated breaking capacity Icn according to EN 60898 at 400V 6kA, Rated breaking capacity Icu according to IEC 60947-2 at 230V 20kA, Rated breaking capacity Icu according to IEC 60947-2 at 400V 10kA, Frequency 50 ... 60Hz, Energy limitation class 3, Overvoltage category 3, Pollution degree 3, additional devices possible, width in modular units 3, protection class (IP) IP20, ambient temperature during operation -25 ... 55°C, connectable conductor cross-section stranded 0.75 ... 25mm², connectable conductor cross-section solid 0.75 ... 35mm²,
Brand
ABB
Breaking capacity in kA
6.00
Class
Circuit breaker
Connection technology
screw terminal
Division units
3
Manufacturer item number
2CDS253001R0104
Manufacturer type
S203-C10
Number of poles
3-pole
old Voltus number
1005617
Rated current in A
10.00
Trigger characteristics
C
Manufacturer information
ABB
ABB Stotz-Kontakt GmbH
Eppelheimer Straße 82
69123 Heidelberg
DE

info.bje@de.abb.com
new.abb.com/de

Hints
  • Bei einem nicht steckerfertigen elektrischen Gerät oder Bauteil dürfen Anschluss und Installation nur von einer qualifizierten Elektrofachkraft durchgeführt werden. Bitte beachte auch die Gebrauchsanweisung.
Recycling & disposal
Informationen zum Bereich Recycling & Entsorgung findest du hier: https://www.voltus.de/umweltschutz/.
