SHELLY W i4 DC Z-Wave-Tasterinterface UP

Z-Wave™ 4-Digital Input Control for Advanced Action Management?

Manually activate or deactivate any created scene, perform synchronized actions, or execute complex trigger scenarios.

• Wave i4 DC is an input reading device (it contains no relays).
• Manual control of other Z-Wave devices (e.g. with a multi-button switch).
• Multiple clicks – activation of up to 12 actions
• Extremely low power consumption: < 0.2 W
• Z-Wave frequency band: 868.4 MHz (CEPT countries).
• Latest technology: Z-Wave 800 series
• Automatic setup with SmartStart
• Security 2 authenticated for highest security
• Over-the-air firmware updates
• Works with Z-Wave certified gateways and over 4,000 Z-Wave devices

A gateway (smart hub) is not included. A gateway (smart hub) is required for device configuration.

WHY WAVE i4 DC?

Replace one of the switches in your room and control every other installed Z-Wave device!

With Wave i4 DC, you can manually activate or deactivate any created scene, perform synchronized actions, or execute complex trigger scenarios. You can control other Z-Wave devices in your network with the push of a button. Thanks to its retrofit design, it is small enough to fit behind any wall switch. Wave i4 can display status and control the action of four inputs, offering maximum convenience by allowing all family members to manually control your smart home.

Z-WAVE

Shelly Qubino works with Z-Wave

By using Z-Wave, smart home products can communicate seamlessly through a centralized smart hub, regardless of their brand or platform! Shelly Qubino devices operate with the latest Z-Wave chip generation (S800), one of the most popular standardised technologies for smart homes worldwide.

_{*Z-Wave devices have specific requirements to function correctly, such as the need to use a supported Z-Wave hub. For more information, please visit the official Z-Wave website: www.z-wave.com}

Works with any Z-Wave gateway

Wave i4 DC is retrofit-ready and designed to fit behind switches/buttons. After installation, you can integrate it into your Z-Wave network (Z-Wave gateway required) and control connected devices from anywhere using your smartphone or tablet. Shelly Qubino devices work with over 4,000 Z-Wave certified devices and gateways.

Functionalities

Z-Wave powered

Add the Wave i4 DC to your Z-Wave network and control it remotely. It is compatible with all certified Z-Wave gateways.

Multi-click support

Up to 12 possible actions. Control lights, close blinds, switch off sockets. Manually control any Z-Wave device in your network. Execute scenes as you wish.

Support for a wide voltage range

Wave i4 DC can be powered with 5-24 V DC.

Associations

Establish direct communication between devices in your local Z-Wave network and set actions without a hub! Configure up to 8 associations on the buttons and activate them manually.

Smart scenes

Create custom scenes by combining the Wave i4 DC with any other Z-Wave device (gateway required).

Endless possibilities

Multiple actions possible

With a simple button press, you can activate up to 12 scenes or actions from other Z-Wave devices in your network. Wave i4 DC supports up to 3 different automation actions per button, making it extremely convenient for quick manual control of a group of devices.

Install Wave i4 DC in the most convenient location for you and use the buttons to simultaneously control lights, blinds, and other devices in specific rooms or throughout the entire building.

Scene activation:

1 click

Turn off multimedia devices

2 clicks

Close blinds

1 long click (hold)

Turn hallway light on/off

Trigger up to 8 actions without a gateway!

With Wave i4, you can establish direct communication between your Z-Wave devices and set various associations without needing a hub! By supporting 2 associations per button, Wave i4 can trigger and execute up to 8 actions, seamlessly controlling multiple Z-Wave devices with a simple button press.

Examples:
1 click (for basic commands)
Turn lights on/off
1 long click (hold) (for multi-level commands)
Dim lights or open/close blinds
Gateway/hub is required for device configuration.

Ultimate convenience

One of the most frustrating situations is realising you forgot to turn off the living room light before going to bed—especially when your phone isn’t nearby. But don’t worry! Wave i4 DC enables manual control of other Z-Wave devices with a switch. Now full control over your home is just a button away!

Control complex scenes

Manually activate or deactivate complex scenes. With Wave i4, you can perform synchronized actions of multiple Z-Wave devices. You can install Wave i4 near your front door and turn all the lights in your house on or off with one button press. This saves time when you are in a hurry.

Perfect combination

Wave i4 DC is perfect for the Shelly Wall Switch for Smart Relays – a switch with 4 buttons. Each button can activate up to 4 different actions. That means with just one 4-button switch, up to 16 scenes can be triggered and executed! Thanks to its compact dimensions and easy wiring, the Shelly Wall Switch fits into any existing switch console or the smallest spaces. No wall space extension or wiring changes are required!

Technical specifications

• Power supply AC: No
• Power supply DC: 5-24 V DC
• Power consumption: < 0.3 W
• Overload protection: No
• Power measurement (W): No
• Works without neutral conductor: No
• Number of inputs: 4
• Range: Up to 40 m indoors (131 ft.) (depending on local conditions)
• Z-Wave repeater: Yes
• CPU: Z-Wave S800
• Z-Wave frequency bands: 868.4 MHz
• Maximum transmitted radio frequency power in band(s): < 25 mW
• Size (H × W × D): 37x42x16 ±0.5 mm / 1.46x1.65x0.63 ±0.02 in
• Weight: 17 g / 0.6 oz.
• Mounting: Wall console
• Screw terminal max. torque: 0.4 Nm / 3.5 lbin
• Conductor cross-section: 0.5 to 1.5 mm² / 20 to 16 AWG
• Length of stripped conductor: 5 to 6 mm / 0.20 to 0.24 in
• Housing material: Plastic
• Colour: Yellow
• Ambient temperature: -20 °C to 40 °C / -5 °F to 105 °F
• Humidity: 30% to 70% RH
